CADintosh X 8.8.3 (665) mac

CADintosh X 8.8.3 (665) mac

CADintosh is a High Performance 2D CAD program for Technical Draftsmen and Designers.
You will benefit from professional and well thought-out features for all your design requirements.

Workflow improvement and usability advantages

• Single window interface (quick access to all features without any additional tool windows)
• Retina display support
• The number of elements is only limited by your available memory
• Pre-settings are saved for each drawing

Key features: Lines and tools

• 8 pens with freely definable line widths and line colors
• 6 line types: full line, dotted line, chain line, dotted line with two dots, zigzag line, short dotted line
• Individual mode: line widths from 0.0 to 99.99 mm, and each element can be designated a different color and width (not compatible to HPGL)
• Functions available for lines, circles, dimensioning, hatching, X lines, etc.

Support for groups and layers

• 32,000 groups
• 1,024 layers
• simple layer management

Compatibility

• Import and export of DXF, HPGL, IGES and PDF
• Unicode support
• Support for symbol libraries for the import and export of symbols
• Alternative units, e.g. for inches
• Runs natively in Mac OS X

Supported Operation Systems
macOS 10.11 or later
